HORIZONTAL PACKAGING MACHINE – YA110

Same perfection even in the highest packaging

The YA-110 horizontal packaging machine with hermetic sealing is designed to provide companies aiming at normal capacity and wide variety of production with a high quality, long-lasting solution. With a modular structure, the machine has excellent packaging ability for high or long products. In the food industry, it usually performs multi-packaging and packaging of block wafers (250 gr - 500 gr), and packs up to 2500 grams in couverture chocolate.

Designed in accordance with user friendly Industry 4.0 standards, the YA-110 also enables you to control data on capacity, energy, productivity, and maintenance from a single point. This enables the user to control each aspect of the production process.

YA110 Specifications;

• Stainless steel plated aluminum chassis
• Adhesive jaw designed with hermetic sealing
• Film flow control with 3 sub adhesive disc groups controlled by servo motor
• Integrated with a servo system, the jaw group provides pressure adjustment, silent movement, and fixed, unique perforated cutting blades.
• Specially designed cover for high security and safety-switch jaw groups
• Vertical and horizontal movement axes controlled by servo
• Packaging materials convenient for hot sealing;
  • Cellophane
  • Pearlite
  • Polypropylene
  • Aluminum laminate
• Compatible with all packaging materials convenient for cold sealing
• Maximum packaging capacity of 60 packages/minute
• Touchscreen and electric control panel on the machine enables
• The machine's touch screen and electrical control panel ensures;
  • Product package height control and access
  • Photocell setting control and access
  • Machine speed control and access
